"Интеллект-02"

Советские программируемые калькуляторы, микрокомпьютеры и большие ЭВМ, не попавшие в другие разделы

Moderator: Shaos

User avatar
Lavr
Supreme God
Posts: 16676
Joined: 21 Oct 2009 08:08
Location: Россия

Post by Lavr »

Интересно, что С.Фролов считает, что "серия "Электроника ИМ-01", "Электроника ИМ-01Т" и "Электроника ИМ-05" - довольно интересные шахматные компьютеры. ... , причем полностью нашей разработки "
С.Фролов wrote:Одна из первых отечественных электронных игр, причем полностью нашей разработки (ленинградское объединение "Светлана").
...
В нашем шахматном компьютере использовался популярный в 1986 году микропроцессор К1801ВМ1. Это - 16-разрядный микропроцессор, широко применявшийся в компьютерах ДВК-2 или семейства БК-0010. Скорее всего, на ДВК-2 он и отлаживался. Примечательно, что сам процессор - производства московского "Ангстрема". В то время на самой "Светлане" выпускался микропроцессор собственного производства К586ВМ1 для компьютеров серии "С5", и почему они взяли чужой, не понятно. Наверно, из-за той возможности отладки.



User avatar
Lavr
Supreme God
Posts: 16676
Joined: 21 Oct 2009 08:08
Location: Россия

Post by Lavr »

Совершенно неожиданно нашел я на жестком диске шахматы на КвикВасюке! :o
Даже не помнил, что у меня такие были. Никогда не играл... :-?


Что они "хотели сказать" в псевдографике - в упор не пойму... :(
Под Вендой это выглядит так и никак по-другому... В любых шрифтах...

Коротко глянул внутрь - есть короткая вставка в кодах и длинная "бадья" описания...

Code: Select all

'-------------------- This is where the chess books are stored --------------
BookData:
  DATA"*rnbqkbnrpppppppp32PPPPPPPPRNBKQBNR*1","E2E4","75","D2D4"
  DATA"*rnbkqbnrppp1pppp11p7P12PPP1PPPPRNBKQBNR*2","B1C3"
  DATA"*rnbkqb1rppp1pppp5H5p7P9N2PPP1PPPPRNBKQB1R*3","G1F3"
  DATA"*rnbqkbnrpppppppp20P11PPPP1PPPRNBQKBNR*1","E7E5"
  DATA"*rnbqkbnrpppp1ppp12p7P8N2PPPP1PPPRNBQKB1R*2","B8C6"
  DATA"*r1bqkbnrpppp1ppp2n9p7P5N2N2PPPP1PPPR1BQKB1R*3","G8F6"
  DATA"*r1bqkb1rpppp1ppp2n2n6p5B1P5N2N2PPPP1PPPR1BQK2R*4","F8C5"
  DATA"END"
'---------- Comments on the program -----------------------------------------
'     This program was orginally written in interpretive basic and as such
' it employs several things that are no longer in vogue. In Ibasic, a pro-
' gram could be made to run faster by two techinques.. 1. by ordering the
' variables in a Dim statement (the most used variables are accessed first.
' and 2. by putting the most use subroutines at the beginning of the program.
' Ibasic would always look for Gotos and Gosubs by starting at the begining
' of the program until it fould the line number called for.
' I also found that, at least in QBasic, that Gosubs run faster than using
' Sub's.
' Here is a summary of the subroutines used in my program.
' 1. InCheck: is actuall two subs in one. First it locates the king and then
'     is finds all pieces attacking that square. It exits the sub upon finding
'     a attacking piece and that pieces location is in the variable "K".
'     This makes makes the program more useful as it can find attacks on other
'     men by setting their location to "K" and going to Attackers:
' 2. Evualuation: is just what the program infers, and can be changed as
'     by the operator/programmer as desired. The weights are for trial pur-
'     poses only and may not represent the Best.
' 3.  Books: is where the program looks to see if an opening book has been
'      defined by the program. It is not the most efficent, but it works.
'      The books can be expanded simply by hitting Control-Break after the
'      program leaves the book subroutine and generates a move on its own.
'      At this point pressing 'F6' and printing Book$ you can see what the
'      chess board looked like at that point. Simply print that line,
'      then press 'F6' again the paste the line at the end of the program,
'      preceded by a "Data" statement. Then enclose you suggest move in
'      quotes. By adding a number in quotes after the move, you can suggest
'      an alternative move. The number is the percentage of the time the
'      program will chose the first move.
' 4.  Genmoves: is where the program generates all of its legal moves. It
'      castle when it can and make enpassant captures when it is possible and
'      they are advantageous. The first thing the program does is find a man
'      of its own color, then it goes to InCheck to see if that move puts its
'      king in check, if so it rejects the move. If not it then goes to the
'      Evualuate subroutine, rates the move, and stores it as Best if it is
'      determined to actually the best, if not it simply returns to GenMove.
'      After finding its best move it falls into the execute the move and
'      does just that. After making its move it switches sides and determines
'      if the enemy king is in check and goes to HumanInput.
'      In the begining of the computer moves "Best is set to 400 if the
'      the program is in check when it starts is move gen. or 200 if it is
'      not. If after trying to find a legal move and it can't it prints the
'      message CheckMate you win or Stalemate, and then quits.
' 5.  HumanInput: only accepts 4 commands: "Q" for quit, "S" for save the game
'      "L" for loading a previously saved game, or a standard move entered as
'      "E2E4" without spaces, however, it in entering a move, you hit a wrong
'      key before the last digit is entered, you can hit "x" or "z" or
'      any other key and it will void the move and try again. It won't do that
'      unless 4 keystrokes have been entered and back spaces are not allowed.
'      It checks that you are moving your own man and that the move is legal.
'      If so, it makes the move, if not it prints "Illegal" goes back to
'      input again. My legal checking is not 100% true, but if you don't
'      cheat, it should work. After making its move it goes to see if its
'      king is in check and set the approiate flag before going to Books:.
'      If it has no more books stored it goes to GenMoves:.
' 6.   The subroutines following HumanInput are for calculating the position
'      of the chessmen on the board and putting them there. Because some
'      moves require moving more that one man "castling" or enpassant there
'      are some subroutines that only make half a move before making a full
'      move later. DON'T REMOVE THESE SUBROUTINES.
' 7. Initialize: creates the chess board and the centercontol board as:
'            chess board                    centercontrol board
'    99,99,99,99,99,99,99,99,99,99       0, 0, 0, 0, 0, 0, 0, 0, 0, 0
'    99, 0, 0, 0, 0, 0, 0, 0, 0,99       0, 0, 0, 0, 0, 0, 0, 0, 0, 0
'    99, 4, 2, 3, 5, 6, 3, 2, 4,99       0, 0, 1, 3, 4, 4, 3, 1, 0, 0
'    99, 1, 1, 1, 1, 1, 1, 1, 1,99       0, 2, 3, 5, 6, 6, 5, 3, 2, 0
'    99, 0, 0, 0, 0, 0, 0, 0, 0,99       0, 4, 5, 7, 8, 8, 7, 5, 4, 0
'    99, 0, 0, 0, 0, 0, 0, 0, 0,99       0, 6, 7, 9,10,10, 9, 7, 6, 0
'    99, 0, 0, 0, 0, 0, 0, 0, 0,99       0, 6, 7, 9,10,10, 9, 7, 6, 0
'    99, 0, 0, 0, 0, 0, 0, 0, 0,99       0, 4, 5, 7, 8, 8, 7, 5, 4, 0
'    99,-1,-1,-1,-1,-1,-1,-1,-1,99       0, 2, 3, 5, 6, 6, 5, 3, 2, 0
'    99,-4,-2,-3,-5,-6,-3,-2,-4,99       0, 0, 1, 3, 4, 4, 3, 1, 2, 0
'    99,99,99,99,99,99,99,99,99,99       0, 0, 0, 0, 0, 0, 0, 0, 0, 0
'    99,99,99,99,99,99,99,99,99,99       0, 0, 0, 0, 0, 0, 0, 0, 0, 0
'    If the computer is black only       The outside edges of this
'    the signs are refersed. The         board are really not needed as
'    computer is always at the top       only the center square witch
'    of the screen. The #'s 99 are       correspond to the real chess
'    always off the board.               board are accessed.
'                                        However. you can put in any values
'                                        that you want to try as these are
'                                        only starting values based upon
'                                        the value of one pawn = 100
'                                        You can try as high as 150 for the
'                                        center squares if you want.
' A final note:
' I have never taken a class on programming, I am self taught, so some of
' my coding may not be the best. If anyone who uses this program wants to
' makes changes, feel free to do so. If you make it play better, or optimize
' any of the coding, please forward the new version of the program so as I
' can record the changes for future releases. I am giving this program as
' freeware to use as you see fit. At the current time it is not very strong.
' It is only a one-ply program, however, it has been stated that the better
' a program plays at one-ply, the better it will play at depth (many-plys).
' You can Email me at: WROGERS824@AOL.COM any comments or changes.
' I deleted the clock subroutines as they messed up the on-board computer
' clock. I just could not figure out how to do it better at this time.
' The program as it stands now has been in existance for 19 years.
' Thanks to all of you. Bill Rogers.
iLavr
User avatar
Stan
Banned
Posts: 397
Joined: 04 Jan 2013 10:09
Location: 95.24.178.158

Post by Stan »

Большое количество ссылок на шахматные программы есть на сайте:
https://chessprogramming.wikispaces.com/6502.

Я посещал его по другому поводу, поэтому не проверял, что там - по этим ссылкам, но потом вспомнил про это обсуждение здесь.

Возможно, ссылки будут кому-либо полезны...
Num Lock
Senior
Posts: 178
Joined: 26 Oct 2006 04:55
Location: Москва

Post by Num Lock »

А кто напишет шахматы на UBASIC?
User avatar
Lavr
Supreme God
Posts: 16676
Joined: 21 Oct 2009 08:08
Location: Россия

Post by Lavr »

Num Lock wrote:А кто напишет шахматы на UBASIC?
На чистом ...BASIC мне шахматы не попадались, но, возможно, есть шанс перенести их с других ЯВУ?

Два коротеньких примера у нас на форуме есть:

JavaScript chess

Code: Select all

for(B=i=y=u=b=i=5-5,x=10,I=[],l=[];B++<304;I[B-1]=B%x?B/x%x<2|B%x<2?7:B/x&4?0:l[i++]="ECDFBDCEAAAAAAAAIIIIIIIIMKLNJLKM@G@TSb~?A6J57IKJT576,+-48HLSUmgukgg OJNMLK  IDHGFE".charCodeAt(y++)-64:7);function X(c,h,e,s){c^=8;for(var o,S,C,A,R,T,G,d=e&&X(c,0)>1e4,n,N=-1e8,O=20,K=78-h<<9;++O<99;)if((o=I[T=O])&&(G=o^c)<7){A=G--&2?8:4;C=o-9?l[61+G]:49;do if(!(R=I[T+=l[C]])&&!!G|A<3||(R+1^c)>9&&G|A>2){if(!(R-2&7))return K;n=G|(c?T>29:T<91)?o:6^c;S=(R&&l[R&7|32]*2-h-G)+(n-o?110:!G&&(A<2)+1);if(e>h||1<e&e==h&&S>2|d){I[T]=n;I[O]=0;S-=X(c,h+1,e,S-N);if(!(h||e-1|B-O|T-b|S<-1e4))return W(),c&&setTimeout("X(8,0,2),X(8,0,1)",75);I[O]=o;I[T]=R}if(S>N||!h&S==N&&Math.random()<.5)if(N=S,e>1)if(h?s-S<0:(B=O,b=T,0))break}while(!R&G>2||(T=O,(G||A>2|(c?O>78:O<41)&!R)&&++C*--A))}return-K+768<N|d&&N}function W(){i="<table>";for(u=18;u<99;document.body.innerHTML=i+=++u%x-9?"<th width=60 height=60 onclick='I[b="+u+"]>8?W():X(0,0,1)'style='font-size:50px'bgcolor=#"+(u-B?u*.9&1||9:"d")+"0f0e0>&#"+(I[u]?9808+l[67+I[u]]:160):u++&&"<tr>")B=b}W()
И Toledo Nanochess - world's smallest chess program in C

Code: Select all

/**************************************************************************\
| Toledo Nanochess (c) Copyright 2009 Oscar Toledo G. All rights reserved  |
| 1258 non-blank characters. Evolution from my winning IOCCC 2005 entry.   |
| o Use D2D4 algebraic style for movements.  biyubi@gmail.com  Aug/10/2009 |
| o On promotion add a number for final piece (3=N, 4=B, 5=R, 6=Q)         |
| o Press Enter alone for computer to play.                                |
| o Full legal chess moves.                     http://nanochess.110mb.com |
| o Remove these comments to get 1326 bytes source code (*NIX end-of-line) |
\**************************************************************************/
char*l="ustvrtsuqqqqqqqqyyyyyyyy}{|~z|{}"
"   76Lsabcddcba .pknbrq  PKNBRQ ?A6J57IKJT576,+-48HLSU";
#define F getchar()&z
#define v X(0,0,0,21,
#define Z while(
#define _ ;if(
#define P return--G,y^=8,
B,i,y,u,b,I[411],*G=I,x=10,z=15,M=1e4;X(w,c,h,e,S,s){int t,o,L,E,d,O=e,N=-M*M,K
=78-h<<x,p,*g,n,*m,A,q,r,C,J,a=y?-x:x;y^=8;G++;d=w||s&&s>=h&&v 0,0)>M;do{_ o=I[
p=O]){q=o&z^y _ q<7){A=q--&2?8:4;C=o-9&z?q["& .$  "]:42;do{r=I[p+=C[l]-64]_!w|p
==w){g=q|p+a-S?0:I+S _!r&(q|A<3||g)||(r+1&z^y)>9&&q|A>2){_ m=!(r-2&7))P G[1]=O,
K;J=n=o&z;E=I[p-a]&z;t=q|E-7?n:(n+=2,6^y);Z n<=t){L=r?l[r&7]*9-189-h-q:0 _ s)L
+=(1-q?l[p/x+5]-l[O/x+5]+l[p%x+6]*-~!q-l[O%x+6]+o/16*8:!!m*9)+(q?0:!(I[p-1]^n)+
!(I[p+1]^n)+l[n&7]*9-386+!!g*99+(A<2))+!(E^y^9)_ s>h||1<s&s==h&&L>z|d){p[I]=n,O
[I]=m?*g=*m,*m=0:g?*g=0:0;L-=X(s>h|d?0:p,L-N,h+1,G[1],J=q|A>1?0:p,s)_!(h||s-1|B
-O|i-n|p-b|L<-M))P y^=8,u=J;J=q-1|A<7||m||!s|d|r|o<z||v 0,0)>M;O[I]=o;p[I]=r;m?
*m=*g,*g=0:g?*g=9^y:0;}_ L>N){*G=O _ h&&c-L<0)P L;N=L _!h&s>1)i=n,B=O,b=p;}n+=J
||(g=I+p,m=p<O?g-3:g+2,*m<z|I[p+=p-O]|m[p<O?1:-1]);}}}}Z!r&q>2||(p=O,q|A>2|o>z&
!r&&++C*--A));}}}Z++O>98?O=20:e-O);P N+M*M&&N>-K+1924|d?N:0;}main(){Z++B<121)*G
++=B/x%x<2|B%x<2?7:B/x&4?0:*l++&31;Z B=19){Z B++<99)putchar(B%x?l[B[I]|16]:x)_
x-(B=F)){i=I[B+=(x-F)*x]&z;b=F;b+=(x-F)*x;Z x-(*G=F))i=*G^8^y;}else v u,5);v u,
1);}}
iLavr
User avatar
Stan
Banned
Posts: 397
Joined: 04 Jan 2013 10:09
Location: 95.24.178.158

Post by Stan »

Lavr wrote:
Num Lock wrote:А кто напишет шахматы на UBASIC?
На чистом ...BASIC мне шахматы не попадались, но, возможно, есть шанс перенести их с других ЯВУ?
Если уж переносить, то может быть, проще это сделать с более близкого языка?

Вот здесь есть исходники шахматного проекта на vBasic:
http://sourceforge.net/projects/vb6ches ... t/download

Я, правда, не совсем понял, какой UBASIC имеется в виду?
Num Lock
Senior
Posts: 178
Joined: 26 Oct 2006 04:55
Location: Москва

Post by Num Lock »

Тот самый, японский и под DOS.
User avatar
Stan
Banned
Posts: 397
Joined: 04 Jan 2013 10:09
Location: 95.24.178.158

Post by Stan »

Num Lock wrote:Тот самый, японский и под DOS.
Я, к сожалению, сделать такого переноса за короткое время не смогу.

Хотя я скачал и опробовал: Simple Chess VB.

Могу только сказать, что на мой взгляд, перенос на QBASIC 4.5 DOS возможен, даже не вникая в алгоритм - механически и по аналогии.
А вот с UBASIC японским и под DOS - мне столкнутся не пришлось.
User avatar
Lavr
Supreme God
Posts: 16676
Joined: 21 Oct 2009 08:08
Location: Россия

Proteus CHESS :)

Post by Lavr »

Lavr wrote:3 - нелогичные, глупые ходы машины...
...
Машина думает... и... БЬЁТ КОРОЛЯ !!!! :D
Я вобще в шахматы играю плохо... но сегодня случилась у меня занимательная партия с Протезусом!.. :o
Я поэтому раньше никогда особо не проверял, как играют в шахматы модели Протезуса, поскольку сам плохо играю.

Но сегодня я модель LCD разрабатывал и пришлось подсматривать, почему у меня мусор по краям LCD вылезает,
а в моделях LCD Протезуса мусора незаметно...
Ну и для динамики LCD играл я с ним в шахматы ну так... особо не утруждаясь...

И как-то так вышло, что я вдруг шах объявляю конем его королику!... :o
А он вместо того, чтобы отойти или прикрыться ну или сдаться, если что не так, вдруг нападает своим
ферзем на моего ферзя! :roll:

Я аж опешил и растерялся... ну мой-то ферзь - под защитой, а его королик-то всё также под боем! :lol:

Поэтому я взял и его королика так и СЪЕЛ! конем!! :esurprised:
А он - раз уж пошла такая пьянка - нет бы отомстил-таки мне... и всё же СЪЕЛ моего ферзя!!! 8)
Нет... он ферзем отскочил и собрался продолжать играть!!! :mrgreen:

В общем, шахматы у Протезуса из того же источника, что и у "Специалиста"... Я "смиялься нипадецки"... :ebiggrin:
You do not have the required permissions to view the files attached to this post.
iLavr
User avatar
Shaos
Admin
Posts: 23990
Joined: 08 Jan 2003 23:22
Location: Silicon Valley

Re:

Post by Shaos »

Lavr wrote:И Toledo Nanochess - world's smallest chess program in C

Code: Select all

/**************************************************************************\
| Toledo Nanochess (c) Copyright 2009 Oscar Toledo G. All rights reserved  |
| 1258 non-blank characters. Evolution from my winning IOCCC 2005 entry.   |
| o Use D2D4 algebraic style for movements.  biyubi@gmail.com  Aug/10/2009 |
| o On promotion add a number for final piece (3=N, 4=B, 5=R, 6=Q)         |
| o Press Enter alone for computer to play.                                |
| o Full legal chess moves.                     http://nanochess.110mb.com |
| o Remove these comments to get 1326 bytes source code (*NIX end-of-line) |
\**************************************************************************/
char*l="ustvrtsuqqqqqqqqyyyyyyyy}{|~z|{}"
"   76Lsabcddcba .pknbrq  PKNBRQ ?A6J57IKJT576,+-48HLSU";
#define F getchar()&z
#define v X(0,0,0,21,
#define Z while(
#define _ ;if(
#define P return--G,y^=8,
B,i,y,u,b,I[411],*G=I,x=10,z=15,M=1e4;X(w,c,h,e,S,s){int t,o,L,E,d,O=e,N=-M*M,K
=78-h<<x,p,*g,n,*m,A,q,r,C,J,a=y?-x:x;y^=8;G++;d=w||s&&s>=h&&v 0,0)>M;do{_ o=I[
p=O]){q=o&z^y _ q<7){A=q--&2?8:4;C=o-9&z?q["& .$  "]:42;do{r=I[p+=C[l]-64]_!w|p
==w){g=q|p+a-S?0:I+S _!r&(q|A<3||g)||(r+1&z^y)>9&&q|A>2){_ m=!(r-2&7))P G[1]=O,
K;J=n=o&z;E=I[p-a]&z;t=q|E-7?n:(n+=2,6^y);Z n<=t){L=r?l[r&7]*9-189-h-q:0 _ s)L
+=(1-q?l[p/x+5]-l[O/x+5]+l[p%x+6]*-~!q-l[O%x+6]+o/16*8:!!m*9)+(q?0:!(I[p-1]^n)+
!(I[p+1]^n)+l[n&7]*9-386+!!g*99+(A<2))+!(E^y^9)_ s>h||1<s&s==h&&L>z|d){p[I]=n,O
[I]=m?*g=*m,*m=0:g?*g=0:0;L-=X(s>h|d?0:p,L-N,h+1,G[1],J=q|A>1?0:p,s)_!(h||s-1|B
-O|i-n|p-b|L<-M))P y^=8,u=J;J=q-1|A<7||m||!s|d|r|o<z||v 0,0)>M;O[I]=o;p[I]=r;m?
*m=*g,*g=0:g?*g=9^y:0;}_ L>N){*G=O _ h&&c-L<0)P L;N=L _!h&s>1)i=n,B=O,b=p;}n+=J
||(g=I+p,m=p<O?g-3:g+2,*m<z|I[p+=p-O]|m[p<O?1:-1]);}}}}Z!r&q>2||(p=O,q|A>2|o>z&
!r&&++C*--A));}}}Z++O>98?O=20:e-O);P N+M*M&&N>-K+1924|d?N:0;}main(){Z++B<121)*G
++=B/x%x<2|B%x<2?7:B/x&4?0:*l++&31;Z B=19){Z B++<99)putchar(B%x?l[B[I]|16]:x)_
x-(B=F)){i=I[B+=(x-F)*x]&z;b=F;b+=(x-F)*x;Z x-(*G=F))i=*G^8^y;}else v u,5);v u,
1);}}
По шахматам от Оскара Толедо завёл отдельную тему:

viewtopic.php?f=81&t=11296

Там кстати чуть более новая версия - от ноября 2009
Я тут за главного - если что шлите мыло на me собака shaos точка net
